Daily Concept Booster Civil Engineering : Volumetric strain

Volumetric strain (ϵv )-



Daily Concept Booster Civil Engineering : Volumetric strain_30.1

(ϵV= ϵx+ϵy+ϵz )
ϵv=(σx/E-μσy/E-μ σz/E)+(σy/E-μ σz/E-μ σx/E)+(σz/E-μ σx/E-μ σy/E)
(ϵv=(σx+σy+σz)/E (1-2μ)=∆V/V)
⇒ in incompressible fluid by applying load there will be no change in volume Strain is zero i.e. poissions ratio is 0.5.

Volumetric strain in circular parallel pipe-

Daily Concept Booster Civil Engineering : Volumetric strain_40.1

(ϵV= ϵL+2ϵD )

Volumetric strain in spherical cell-

Daily Concept Booster Civil Engineering : Volumetric strain_50.1
(ϵv=3ϵD )



Boost your preparation with the all-new Concept Booster Series by Adda247 Engineering Jobs, this series aims to target all the important engineering exams such as SSC JE 2022, GATE 2022, ESE 2022, and many more. Please reach out to us with your feedback in the comment section.
