A cantilever beam subjected to point load of 10 units at its free end is having maximum deflection of 1250/(3EI) units. Find the slope at its free end

Question

A cantilever beam subjected to point load of 10 units at its free end is having maximum deflection of 1250/(3EI) units. Find the slope at its free end.

250/(EI) units

125/(EI) units

62.5(EI) units

12.5/(EI) units

Solution

Correct option is B
